6-channel Studio mixer

✓ 4 saluran mono dan 1 saluran stereo dengan kontrol volume independen

✓ Bluetooth® receiver dan USB recorder/player

✓ 16 digital effects processor

✓ Audio USB untuk koneksi ke PC sebagai kartu audio

✓ Fungsi live streaming



Spesifikasi

Fitur :

• Mixer stereo 4 saluran mono dan 1 saluran.
• Input/output audio USB untuk koneksi PC sebagai kartu audio Plug and Play di Windows dan Mac, memungkinkan pemutaran audio simultan dari PC dan perekaman.
• 4.2 Bluetooth Receiver.
• USB recorder/player.
• 16 digital effects processor.

USB Player :

• Plays or records MP3 files.
• USB-C port for PC connection as Plug and Play audio card on Windows and Mac.
• Stereo line-level auxiliary input.

Inputs :

• 4 balanced micro/lines, combo (XLR, 600 Ω 15 mV RMS and 6.3 mm jack, 47.000 Ω 200 mV RMS).
• 1 balanced stereo line channel, 2 x 6.3 mm jack, 47,000 Ω 250 mV RMS.
• 1 stereo auxiliary, 3.5 mm jack, 47,000 Ω 1 V RMS.
• 1 stereo auxiliary (live streaming), 3.5 mm TRRS jack, 47.000 Ω 250 mV RMS.
• 1 microphone, 3.5 mm jack TS, 600 Ω 15 mV RMS.
• 1 USB/PC, stereo.

Controls :

• 6 controls per channel: gain, 3-band EQ, pan, volume, and clip light indicator.
• Effects and level selection.
• Headphone volume.
• Independent volume control for main and aux/monitor output.

Function :

• 3-band equaliser per channel.
• Overload light indicator and master output level light indicator.
• Live streaming.
• USB/PC.

Outputs :

• 1 balanced/unbalanced stereo main, 2 x 6.3 mm jack/2 x RCA, 2.5 V RMS.
• 1 balanced aux/monitor, 6.3 mm jack, 2 V RMS.
• 1 stereo auxiliary (live streaming), 3.5 mm TRRS jack, 0.5 V RMS.
• 1 stereo headphone, 3.5 mm jack.
• 1 USB/PC, stereo.

Phantom : 48 V on channels 1 and 2, selectable
Response : 20-20,000 Hz .
Distortion : Harmonic: 0.04 %.
S/N Ratio : > 65 dB
Power Supply : 5 V DC, 2.1 A with included adapter .
Dimensi : 210 x 70 x 237mm depth.
Berat : 1.1 kg.
Aksesoris :

• 3.5 mm TRRS male-to-male audio jack cable.
• USB-A to USB-C power cable.
• USB power adapter.
